4-core single mode (G.652D) underwater fibre optic cable. PUR jacket, deep-sea rated, for high-bandwidth ROV data links and subsea optical networks.
This 4-core single-mode underwater fibre optic cable is designed for demanding subsea optical transmission applications. Using G.652D (OS2) single-mode fibres, it delivers high bandwidth at low attenuation over long cable runs -- ideal for ROV tethers, subsea observatory links, and deep-sea communication networks. The PUR outer jacket provides excellent resistance to seawater, UV, and abrasion.
| Parameter | Specification |
|---|---|
| Fibre Count | 4 x Single-Mode |
| Fibre Standard | ITU-T G.652D (OS2) |
| Attenuation | ≤0.35 dB/km @1310 nm; ≤0.20 dB/km @1550 nm |
| Jacket Material | Polyurethane (PUR) |
| Temperature Range | -30°C to +80°C |
| Depth Rating | Up to 6,000 m (with armour) |
| Fibre Protection | Loose tube, gel-filled, Kevlar yarn |
| Min Bend Radius | 20x OD |
Request fibre test reports and custom cable specifications: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
Yes. G.652D single-mode fibre is fully compatible with DWDM (Dense Wavelength Division Multiplexing) systems. Multiple high-capacity channels can be transmitted on a single fibre, making this 4-core cable capable of carrying 40+ DWDM channels per fibre.
Yes. We commonly produce hybrid versions combining 4SM fibres with power conductors (e.g. 2 x 1.5mm2) in a single cable. See our fibre optic hybrid cable range or contact us with your combined requirements.
