4 power conductors 18AWG + 4 Ethernet pairs 24AWG underwater cable. PUR jacket, combined power and Ethernet for ROV systems and subsea multi-device networks.
Combining 4 x 18AWG power conductors with 4 shielded Ethernet twisted pairs at 24AWG in a single PUR-jacketed cable, this underwater cable provides both power distribution and multi-channel Ethernet connectivity for ROV and subsea systems. Four Ethernet pairs support simultaneous connection of up to 4 devices with independent 100 Mbps links, while the 4-core power section handles multi-phase or multi-circuit power distribution.
| Parameter | Specification |
|---|---|
| Power Conductors | 4 x 18AWG (stranded tinned copper) |
| Ethernet Pairs | 4 x 2 x 24AWG (foil shielded twisted) |
| Voltage Rating | 300V RMS |
| Jacket Material | Polyurethane (PUR) |
| Temperature Range | -30°C to +80°C |
| Depth Rating | Up to 4,000 m |
| Shielding | Per-pair foil + overall braid |
Request a quote or custom configuration: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
The 24AWG pairs support 100 Mbps (Cat5e equivalent) per pair. For Gigabit Ethernet, we recommend upgrading to 23AWG or 22AWG pairs. Contact us to specify your bandwidth requirements.
Yes. Kevlar braid can be added between the core assembly and the PUR jacket, providing tensile strength suitable for ROV tether deployments. We will quote based on your target tensile load.
