7 twisted pairs 22AWG Ethernet + 2 x 18AWG power conductors underwater cable. PUR jacket, for ROV multi-device Ethernet networks and subsea control systems.
This high-pair-count underwater cable combines 7 twisted Ethernet pairs at 22AWG with 2 x 18AWG power conductors in a single PUR-jacketed assembly. It is designed for complex ROV systems where multiple Ethernet devices (cameras, sensors, thruster controllers, navigation instruments) must be networked alongside power delivery, all within a single drag-optimised tether cable.
| Parameter | Specification |
|---|---|
| Ethernet Pairs | 7 x 2 x 22AWG (twisted, foil shielded) |
| Power Conductors | 2 x 18AWG |
| Voltage Rating | 300V RMS |
| Jacket Material | Polyurethane (PUR) |
| Temperature Range | -30°C to +80°C |
| Depth Rating | Up to 4,000 m |
| Shielding | Per-pair foil + overall braid |
| Ethernet Speed | 100 Mbps per pair (Cat5e equivalent) |
Enquire about high-pair-count underwater ethernet cable solutions: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
Yes. All 7 pairs are individually shielded and can operate independently. Combined with a subsea Ethernet switch or multiplexer, they can support 7 separate 100 Mbps channels simultaneously.
For PoE applications, the dedicated 2 x 18AWG power conductors are preferred over injecting PoE through the data pairs. However, PoE-compatible configurations can be discussed -- contact us with your power budget requirements.
