1 twisted pair 20AWG Ethernet + 5 conductors 20AWG underwater cable. PUR jacket, for ROV and subsea applications combining Ethernet with multi-channel signal.
A compact underwater cable combining a single Ethernet twisted pair at 20AWG with 5 individual signal conductors at 20AWG in a PUR-jacketed assembly. This cable provides Ethernet connectivity plus multiple discrete control channels in a single cable, ideal for ROV subsystems and subsea instrumentation where both Ethernet communication and analogue/digital control signals are required.
| Parameter | Specification |
|---|---|
| Ethernet Pair | 1 x 2 x 20AWG (shielded twisted pair) |
| Signal Conductors | 5 x 20AWG (individually insulated) |
| Voltage Rating | 300V RMS |
| Jacket Material | Polyurethane (PUR) |
| Temperature Range | -30°C to +80°C |
| Depth Rating | Up to 3,000 m |
| Shielding | Foil on Ethernet pair + overall braid |
For specifications and custom configuration enquiries: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
The 20AWG shielded twisted pair supports 10/100 Mbps Ethernet (Cat5 equivalent) over typical subsea cable runs up to 100 m. For longer distances or higher speeds, we recommend fibre optic hybrid alternatives.
Yes. The 5 x 20AWG conductors can carry RS-485, RS-232, 0--10V analogue, 4--20 mA current loop, or discrete digital signals. Pair them as needed for your control system interface requirements.
1X2X20AWG+5X20AWG Underwater Ethernet cables
1 twisted screened pair, 20 AWG Screen with foil and drain wire
5 conductors, 20 AWG Nom. cable OD: 0.339'', 8.62 mm
