5 conductors 20AWG subsea polyurethane cable. 5-channel signal and control for ROV and subsea instrument systems. PUR jacket, seawater resistant.
A 5-core subsea cable with 5 x 20AWG conductors in a polyurethane jacket. Suitable for ROV control lines, subsea instrument interfaces, and multi-function signal cables where 5 independent channels are needed. Compact design with colour-coded conductors for easy identification during installation and maintenance.
| Parameter | Specification |
|---|---|
| Conductors | 5 x 20AWG |
| Jacket Material | Polyurethane (PUR) |
| Voltage Rating | 300V RMS |
| Temperature Range | -30°C to +80°C |
| Depth Rating | Up to 3,000 m |
| Shielding | Optional (screened version available) |
| Colour Coding | Yes -- 5-colour standard |
For 5-core subsea cable specifications and pricing: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
Yes. Individual conductor screening and/or an overall braid shield can be added. The screened version is recommended for applications near thruster motor drives or power electronics where EMI interference may affect signal integrity.
Yes. We supply 5-pin underwater connector assemblies (SubConn-compatible or custom) with this cable. Specify pin count, depth rating, and mating half requirements when ordering.
