16 individually screened conductors 20AWG underwater polyurethane cable. High conductor count for ROV umbilicals and subsea multi-function control systems.
This high-conductor-count underwater cable features 16 individually screened 20AWG conductors in a single PUR-jacketed cable. It enables complex ROV umbilical and subsea control applications where 16 independent signal channels are required -- such as multi-thruster control, multiple valve solenoids, sensor inputs, and lighting control -- all in a single, compact cable assembly.
| Parameter | Specification |
|---|---|
| Conductors | 16 x 20AWG (individually screened) |
| Jacket Material | Polyurethane (PUR) |
| Voltage Rating | 300V RMS |
| Temperature Range | -30°C to +80°C |
| Depth Rating | Up to 4,000 m |
| Overall Shield | Foil + braid |
| Colour Coding | Yes -- 16 distinct conductor colours |
Discuss 16-core umbilical requirements: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
Each conductor is individually colour-coded using a 16-colour scheme (or numerical labelling for custom orders). This ensures correct identification during termination and maintenance even after long cable runs.
With foam filler elements and appropriate Kevlar reinforcement, a neutrally buoyant version of this cable can be produced. Specify your target depth and buoyancy requirement when ordering.
