Multicore single-mode fiber optic underwater cable for subsea signal transmission. OS2 fibers, PUR jacket, for ROV, ocean observatory, and subsea LAN high-bandwidth fiber links.
The multicore underwater single-mode fiber optic cable provides high-bandwidth optical signal transmission in subsea environments. OS2 single-mode fibers (9/125 μm) support transmission of 10 Gbps, 40 Gbps, 100 Gbps, and DWDM wavelength-division multiplexed signals over kilometre-scale cable runs with essentially zero bandwidth limitation. Suitable for ocean observatories, ROV high-bandwidth tethers, and subsea LAN infrastructure.
| Parameter | Specification |
|---|---|
| Fiber Type | OS2 Single-mode (9/125 μm ITU-T G.652.D) |
| Fiber Count | 2 / 4 / 6 / 8 / 12 / 24 (specify) |
| Buffer | Loose-tube gel-filled or dry blocked |
| Strength Member | Kevlar aramid yarn + optional central steel |
| Outer Jacket | Polyurethane (PUR) |
| Attenuation | ≤0.2 dB/km @ 1550 nm |
| Depth Rating | Up to 6,000 m |
| Colour | Black / yellow |
Request datasheet, custom length, or OEM pricing: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
OS2 (ITU-T G.652.D) has a lower attenuation (≤0.2 dB/km at 1550 nm vs ≤0.35 dB/km for OS1) and is designed for outside plant (OSP) applications including direct burial and underwater deployment. OS1 is for indoor use only. For any underwater cable, always specify OS2.
For a standard ROV with HD video and Ethernet: 2 fibers (one Tx, one Rx) support a single 10 Gbps link or multiple 1 Gbps CWDM channels. 4 fibers provide redundancy. 6--12 fibers are used in work-class ROVs with multiple HD/4K cameras and high-bandwidth control links, plus spare fibers for future expansion.
