Underwater CCTV camera cable for GoPro and action cameras. Combined power and video signal in PUR jacket for subsea CCTV, inspection, and camera systems.
The underwater CCTV camera cable is designed for use with GoPro camera housings, action camera subsea enclosures, and fixed underwater CCTV systems. It combines coaxial video signal and power supply conductors in a single compact PUR-jacketed run, enabling clean and reliable camera installation in ROV systems, underwater inspection vehicles, and fixed subsea camera stations without the need for separate power and video cables.
| Parameter | Specification |
|---|---|
| Signal Core | Coaxial (75 Ohm RG-type) for CVBS / AHD / TVI video |
| Power Cores | 2 x power conductors for camera supply |
| Jacket | Polyurethane (PUR) |
| Depth Rating | Up to 300 m standard (600 m+ on request) |
| Custom | Cable length, connector type, additional signal cores |
| Colour | Black |
| Flexibility | High flex |
| Camera Compatibility | GoPro housings, IP67/IP68 CCTV cameras, ROV cameras |
Request datasheet, custom length, or OEM pricing: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
GoPro cameras (Hero series) typically require 5V USB power. The power cores in this cable supply the regulated 5V from a topside USB power supply or DC-DC converter. Specify your camera model when ordering and we will confirm the correct power conductor sizing and connector interface.
Yes. The coaxial core in this cable is suitable for analog HD formats including AHD (1080p), TVI (1080p/4MP), and CVI up to approximately 500 m cable length. Beyond this, use a signal amplifier or switch to IP camera with Cat6 cable.
