10 Pin Micro Circular Wet-Pluggable Underwater Connector -- MCBH10 & MCIL10
Shanghai Kabel Intelligence Technology Co., Ltd supplies 10-pin micro circular underwater connectors for ROV, AUV, submarine, and subsea instrumentation. The 10-contact configuration provides sufficient conductor capacity for combined power-data-control circuits in a single compact wet-mateable interface. Rated to 7,000 m depth, IP68 sealed, SubConn® MCBH10/MCIL10 compatible.
Available Models
|
Type
|
Part Number
|
Gender
|
|
Bulkhead
|
MCBH10M
|
Male (pins)
|
|
Bulkhead
|
MCBH10F
|
Female (sockets)
|
|
In-Line
|
MCIL10M
|
Male (pins)
|
|
In-Line
|
MCIL10F
|
Female (sockets)
|
|
Dummy Cap
|
MCDC10F
|
Protective cap
|
Technical Specifications
-
Contact count: 10
-
Depth rating: 7,000 m (700 bar)
-
IP rating: IP68
-
Voltage: 600 V AC/DC
-
Current per contact: 10 A
-
Shell: Hard-anodized aluminium / Titanium option
-
Insulator: PEEK
-
Contacts: Gold-plated copper alloy
-
Sealing: Dual O-ring per contact + face seal
-
Hydrostatic test: 600 psig, certificate included
-
Mating cycles: 500+
-
Compatibility: SubConn MCBH10 / MCIL10
Typical 10-Pin Wiring Allocations
-
2 contacts: 24 V DC power + return
-
2 contacts: RS-485 bus (A+B)
-
2 contacts: RS-232 Tx/Rx
-
2 contacts: Analog sensor signal + shield ground
-
2 contacts: Spare / relay trigger
Applications
-
ROV camera and payload connector panels
-
AUV sensor interface connectors
-
Underwater acoustic modems
-
Subsea control module (SCM) I/O connectors
-
Oceanographic buoy and mooring instruments
-
Submarine and UUV interface connectors
