1-contact high-current subsea power connector for ROV and offshore single-circuit applications. IP68, stainless steel. Contact sales@rovcable.com.
The Power 1-Contact subsea connector from Shanghai Kabel Intelligence Technology Co., Ltd is the simplest and most compact connector in the High Power Series -- a single-pin, high-current waterproof connector for applications requiring one dedicated power circuit. IP68 sealed with a robust 316L stainless steel body, it is suitable for ROV lighting, single-phase drives, and offshore single-circuit power feeds.
| Parameter | Value |
|---|---|
| Contact Count | 1 |
| Current Rating | Up to 100 A (contact size dependent) |
| Voltage Rating | Up to 1000 V DC/AC rms |
| IP Rating | IP68 |
| Housing Material | 316L Stainless Steel |
| Contact Plating | Silver or Gold (specify) |
| Operating Depth | 300 m standard; up to 3000 m custom |
| Mating Cycles | ≥500 |
Enquire about current rating, contact size, and cable assembly options: sales@rovcable.com
Up to 100 A for the standard large-pin version. Current capacity depends on pin diameter -- contact us with your load requirement for the appropriate selection.
A single-contact connector has no polarity in the mating key, but the cable termination itself (positive or negative) is defined during assembly. Specify polarity requirements when ordering.
Yes -- the standard electrical rating is 1000 V DC rms. This makes it compatible with HVDC subsea power distribution and high-voltage thruster systems.
