Ethernet Circular 8-contact subsea connector for ROV, AUV and underwater network systems. IP68, stainless steel. Contact sales@rovcable.com.
The Ethernet Circular 8-contact subsea connector from Shanghai Kabel Intelligence Technology Co., Ltd provides a compact, IP68-rated solution for standard 8-wire Ethernet connectivity in underwater environments. Supporting 100BASE-TX and 1000BASE-T (Gigabit Ethernet), it is the go-to choice for ROV cameras, AUV network links, and subsea sensor nodes.
| Parameter | Value |
|---|---|
| Total Contacts | 8 |
| IP Rating | IP68 |
| Ethernet Standard | 100BASE-TX / 1000BASE-T (Cat5e/Cat6) |
| Housing Material | 316L Stainless Steel |
| Contact Plating | Gold |
| Sealing | Double O-ring |
| Operating Depth | 300 m standard; up to 3000 m custom |
| Mating Cycles | ≥500 |
| Form Factor | Circular / Panel-mount |
Enquire about custom pin-outs, shielded variants, or cable assemblies: sales@rovcable.com
Yes -- the 8 contacts follow the standard T568B wiring map, allowing direct connection to Cat5e or Cat6 Ethernet cables with full compatibility with standard network equipment.
The connector supports 1000BASE-T (Gigabit Ethernet), providing bandwidth suitable for HD video, sonar data streams, and high-speed sensor telemetry.
Yes -- a shielded version with a separate drain wire contact is available for EMI-sensitive environments. Specify STP when ordering.
