Coax Series multi-configuration subsea coaxial underwater connectors for ROV, AUV, and oceanographic sensors. IP68, gold contacts, depth-rated. sales@rovcable.com.
The Coax Series from Shanghai Kabel Intelligence Technology Co., Ltd offers the broadest selection of subsea coaxial connector configurations for ROV, AUV, and oceanographic sensor systems. From single-coax to multi-coax assemblies, every unit features IP68 sealing, gold-plated contacts, and a 316L stainless steel body for long-term reliability at depth.
| Parameter | Value |
|---|---|
| Available Configurations | Single coax / Dual coax / Multi-coax |
| IP Rating | IP68 |
| Impedance | 50 Ohm / 75 Ohm |
| Contact Plating | Gold (1 µm min) |
| Housing Material | 316L Stainless Steel / Polyurethane |
| Operating Depth | 300 m standard; up to 6000 m custom |
| Frequency Range | DC to 3 GHz |
| Mating Cycles | ≥500 |
| Operating Temperature | -40°C to +85°C |
Contact us for configuration selection or custom requirements: sales@rovcable.com
The Coax Series is available with 1 to 4 coaxial contacts in standard configurations. Larger multi-coax assemblies are available on custom order.
Yes -- mixed 50 ohm and 75 ohm inserts within a single multi-coax connector body are available as a custom option. Contact us with your circuit requirements.
All Coax Series connectors meet IP68 sealing requirements tested to 1 m / 30 min as standard. Higher-depth pressure testing is available on request.
