Aviation plug connector with push-pull or screw lock coupling. Multi-pin circular design for industrial instruments, ROV tether interfaces, and panel-mounted applications.
Our aviation plug connector range covers standard circular multi-pin connectors in screw-lock and push-pull coupling styles. Built to aviation connector standards, these connectors provide reliable, vibration-resistant connections for industrial instruments, ROV tether interfaces, deck equipment, and panel-mounted applications. The gold-plated copper alloy contacts ensure low contact resistance and long service life.
| Parameter | Specification |
|---|---|
| Coupling | Screw lock (standard) / Push-pull (optional) |
| Pin Count | 2--16 (model dependent) |
| Contact Rating | 5--10A per contact |
| Voltage Rating | 250V AC/DC |
| IP Rating | IP65 (mated) |
| Shell Material | Zinc alloy / Aluminium (nickel or chrome plated) |
| Contact | Copper alloy, gold-plated |
| Temperature Range | -25°C to +85°C |
Order aviation circular connectors with custom pin counts: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
Yes. Replacement contacts (pins and sockets) are available for all standard aviation connector shell sizes. We supply both crimp and solder contact variants to accommodate field repair without requiring a complete connector replacement.
Yes. All models in our aviation plug range include a panel-mount (bulkhead) socket option with a threaded or flange mounting arrangement. The cable plug mates with the panel socket using the standard screw-lock or push-pull coupling.
