Aviation plug connector 2-16 core, GX16/GX20 series. Screw lock, IP65 rated, suitable for industrial signal, ROV tether, and subsea instrument interface connections.
The aviation plug connector in our 2-16 core range uses the GX16 / GX20 standard circular connector design with a reliable screw-lock coupling and IP65 sealing. Available in 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14, and 16 core versions, these connectors are widely used in industrial instrumentation, ROV tether terminations, and subsea instrument interface applications requiring a cost-effective, reliable connection.
| Parameter | Specification |
|---|---|
| Connector Series | GX16 (16 mm) / GX20 (20 mm) |
| Core Count | 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 12 / 14 / 16 |
| Contact Rating | 5A per contact (standard) |
| Voltage Rating | 250V AC/DC |
| IP Rating | IP65 (mated) |
| Locking | Screw-thread coupling |
| Shell Material | Zinc alloy / aluminium |
| Contact Material | Copper alloy, gold-plated |
| Temperature Range | -25°C to +85°C |
Contact us to order aviation plug connectors in any core count: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
GX16 has a 16 mm outer shell diameter and is available in 2--10 core versions. GX20 has a 20 mm shell diameter, supporting up to 16 cores with larger contact spacing, suitable for slightly higher current or pin-count requirements. Choose GX16 for compact installations and GX20 where more pins or higher current are needed.
Yes. The IP65 rating means they are protected against dust ingress and low-pressure water jets, making them suitable for outdoor, marine deck, and equipment enclosure applications. For fully submerged use, please see our SubConn-compatible and deep-rated underwater connectors.
Standard GX16/GX20 cores are 2--16. For non-standard configurations or higher current contacts, contact us and we will advise on the best connector family for your requirements.
