MCDLSF female locking sleeve with metal O-ring for underwater electrical connectors. Secures mated connector pairs against accidental decoupling in ROV and subsea applications.
The MCDLSF female locking sleeve with metal O-ring is a retention accessory designed to secure mated underwater electrical connector pairs against vibration, current drag, and accidental decoupling. Compatible with SubConn-equivalent MCIL/MCBH series connectors, this locking sleeve is manufactured in 316L stainless steel for maximum corrosion resistance in seawater and marine environments.
| Parameter | Specification |
|---|---|
| Model | MCDLSF (female locking sleeve) |
| Material | 316L Stainless Steel |
| Sealing | Metal O-ring (contact us for size) |
| Compatibility | SubConn-equivalent MCIL/MCBH connectors |
| Finish | Electropolished / passivated |
| Depth Rating | Matches connector pair rating (up to 6,000 m) |
| Function | Locks mated connector pair -- prevents decoupling |
Request MCDLSF locking sleeve sizes and compatibility data: sales@rovcable.com -- Shanghai Kabel Intelligence Technology Co., Ltd.
MCDLSF is the female locking sleeve (installed on the female connector half), while MCDLSM is the male locking sleeve (installed on the male connector half). In a mated pair, both sleeves work together to secure the connection. Some configurations use only one sleeve; contact us to confirm the correct sleeve for your connector pair.
Yes. The metal O-ring in MCDLSF sleeves is reusable through multiple mate/demate cycles under normal conditions. Inspect the O-ring for deformation or scratches before each re-use. Replace if any damage is observed to maintain the secure locking function.
